Kaeser MOBILAIR M480 Towable Rotary Screw Air Compressor - 1700 CFM, Diesel
Kaeser MOBILAIR M480 — 1700 CFM @ 100 psig, Cummins QSG 12 Tier 4 Final, 443 BHP, 211 gal tank.
Top of the MOBILAIR line. 1700 CFM at 100 psig from a 443 BHP Cummins QSG 12, on a tandem-axle trailer with a 211-gallon tank. Two variable pressure ranges - 100 to 125 and 125 to 205 psig - so it adapts to the job rather than the other way around. This is large-diameter pipeline, deep foundation and major infrastructure equipment; at this size the aftercooler is close to mandatory.
Every MOBILAIR shares the same core engineering. The large, slow-turning SIGMA PROFILE® airend delivers 15–20% more air per gallon of fuel than comparable units, which is the single biggest line item over a machine's life. The anti-frost valve holds discharge air temperature high enough that ambient moisture will not freeze in the tool, protecting air motors and extending tool service life. Heavy-duty chassis and canopy resist corrosion; package airflow is routed to keep the engine cool under load; and the cold-start battery means the unit turns over in winter. Towable models ride on torsion bar suspension with even weight distribution.
Specifications
| Model | M480 |
|---|---|
| Free air delivery | 1700 CFM @ 100 psig |
| Engine | Cummins QSG 12 Tier 4 Final |
| Fuel | Diesel |
| Brake horsepower | 443 BHP @ full load |
| Full load speed | 2000 rpm |
| Off load speed | 1200 rpm |
| Drive type | Gear |
| Fuel tank capacity | 211 gal |
| Air discharge outlets | 2 x 1" + 1 x 2-1/2" (price list also cites 1 x 3" ASME flange) |
| Dimensions (L x W x H) | 241 x 96 x 100 in. (towbar) |
| Shipping weight | 12,471 lb (approx.) |
| Sound level | 76 dB(A) max at 23 ft |
| Mounting | Tandem-axle towable |
Free air delivery by pressure
| Pressure | Delivery |
|---|---|
| 100 psig | 1700 CFM |
| 125 psig | 1575 CFM |
| 145 psig | 1500 CFM |
| 175 psig | 1420 CFM |
| 205 psig | 1330 CFM |
Specifications from the Kaeser MOBILAIR price list effective 07-01-26 and the USMOBILAIR brochure 01/26. EX WORKS shipping point. Prices and specifications subject to change without notice.
Specifications
| Air Treatment Package | Standard - no aftercooler or Aftercooler + centrifugal separator or Aftercooler + separator + filter |
| Cold Weather Package | Standard ambient or Low temperature package - consult factory |
| Discharge Pressure | Standard pressure or 100 - 125 variable or 125 - 205 variable |
| Mounting | Skid mounted or Stationary (anti-vibration pads) or Tandem-axle towable (standard) |
