Kaeser MOBILAIR M118 Towable Rotary Screw Air Compressor - 405 CFM, Diesel
Kaeser MOBILAIR M118 — 405 CFM @ 100 psig, Deutz TCD 3.6 L4 Tier 4 Final, 107 BHP, 45 gal tank.
First of the powerhouse frames. 405 CFM off a direct-drive Deutz TCD 3.6, with a 45-gallon tank and off-load speed dropping to 1500 rpm so it is not burning fuel while the crew repositions. Pipeline work, large sandblast pots, multiple rock drills - this is the size where a single machine replaces a bank of smaller ones.
Every MOBILAIR shares the same core engineering. The large, slow-turning SIGMA PROFILE® airend delivers 15–20% more air per gallon of fuel than comparable units, which is the single biggest line item over a machine's life. The anti-frost valve holds discharge air temperature high enough that ambient moisture will not freeze in the tool, protecting air motors and extending tool service life. Heavy-duty chassis and canopy resist corrosion; package airflow is routed to keep the engine cool under load; and the cold-start battery means the unit turns over in winter. Towable models ride on torsion bar suspension with even weight distribution.
Specifications
| Model | M118 |
|---|---|
| Free air delivery | 405 CFM @ 100 psig |
| Engine | Deutz TCD 3.6 L4 Tier 4 Final |
| Fuel | Diesel |
| Brake horsepower | 107 BHP @ full load |
| Full load speed | 2200 rpm |
| Off load speed | 1500 rpm |
| Drive type | Direct |
| Fuel tank capacity | 45 gal |
| Air discharge outlets | 3 x 3/4" + 1 x 1-1/2" NPTF |
| Dimensions (L x W x H) | 188 x 74 x 68 in. (towbar); brochure lists 69 in. height |
| Shipping weight | 4,850 lb (approx.) |
| Sound level | 76 dB(A) max at 23 ft |
| Mounting | Towable |
Free air delivery by pressure
| Pressure | Delivery |
|---|---|
| 100 psig | 405 CFM |
| 145 psig | 360 CFM |
Specifications from the Kaeser MOBILAIR price list effective 07-01-26 and the USMOBILAIR brochure 01/26. EX WORKS shipping point. Prices and specifications subject to change without notice.
Specifications
| Air Treatment Package | Standard - no aftercooler or Aftercooler + centrifugal separator or Aftercooler + separator + filter or Aftercooler + separator + heater or Aftercooler + separator + heater + filter |
| Cold Weather Package | Standard ambient or Low temperature package (min. ambient -13 °F) |
| Discharge Pressure | Standard pressure or 145 psig |
| Mounting | Towable (standard) or Skid mounted or Stationary (anti-vibration pads) |
